材(cai)質

C

Si

Mn

Cr

Ni

Mo

耐溫度(du)

特(te)性(xing)

A3

≤0．22

≤0.3

≤0.65

-

-

-

400°

普通網帶

45#

≤0.50

≤0.37

≤0.80

≤0.25

≤0.25

500°

普(pu)通(tong)網(wang)帶(dai)

1cr13

≤0.15

≤0.6

≤0.6

-

12-14

-

650 °

普(pu)通網(wang)帶(dai)

1cr17

≤0.15

≤0.6

≤0.6

-

12-18

-

650 °

普(pu)通(tong)網帶(dai)

SUS304M

≤0.06

≤1.0

≤2.0

8.9-10.0

18-20

-

750°

普(pu)通網帶(dai)

SUS304L

≤0.03

≤1.0

≤2.0

9-13

18-20

-

750 °

耐晶(jing)界腐蝕

SUS316

≤0.08

≤1.0

≤2.0

10-14

16-18

2-3

750°

耐(nai)腐蝕(shi)

SUS316L

≤0.03

≤1.0

≤2.0

12-15

16-18

2-3

750°

耐(nai)晶界腐(fu)蝕

SUS309S

≤0.08

≤1.0

≤2.0

12-15

22-24

-

950 °

耐長時(shi)間高(gao)溫

SUS310S

≤0.08

≤1.5

≤2.0

19-22

24-26

-

(國産(chan))1000 °
(進口(kou))1150 °

耐高溫及高(gao)溫拉(la)伸(shen)

SUS314

≤0.25

≤1.5-3.0

≤2.0

19-22

23-26

-

(國(guo)産(chan))1050 °
(進口(kou))1250 °

在(zai)310基礎上提高(gao)抗(kang)氧性

Cr20Ni80

≤0.15

≤0.4-1.3

≤0.7

75-78

20-23

-

1200 °

耐高溫(wen)、抗(kang)氧化(hua)

節(jie) 距

滾(gun) 子
直(zhi) 逕(jing)

內(nei)節(jie)
內(nei)寬(kuan)

銷軸
直(zhi)逕(jing)

銷軸(zhou)
長(zhang)度(du)

連(lian)接(jie)
銷(xiao)長(zhang)

內鏈(lian)
闆(ban)高(gao)

平(ping)檯
高度

坿孔(kong)
橫距(ju)

坿孔(kong)
縱距(ju)

坿孔
直逕

C208B
C208BL

25.4

8.51
15.88

7.75

4.5

16.7

18.2

11.8

2.00

9.10

12.7

4.5

C210A
C210AL

31.75

10.16
19.05

9.40

5.08

20.9

22.2

15.09

2.00

11.10

11.9

5.5

C212A
C212AL

38.1

11.91
22.23

12.57

5.94

25.9

28.3

18.00

2.50

14.70

14.3

5.5

C216A
C216L

50.8

15.88
28.58

15.75

7.92

32.7

36.5

24.00

3.00

19.10

19.1

6.8

C208 B 滾子(zi)直(zhi)逕15.88

C210A 滾子(zi)直(zhi)逕(jing) 19.05

C212A滾(gun)子直(zhi)逕(jing) 22.23

C216A滾(gun)子直(zhi)逕(jing) 28.58

外(wai)逕(jing)

節(jie)逕(jing)

齒根(gen)逕(jing)

外(wai)逕(jing)

節(jie)逕(jing)

齒根逕(jing)

外(wai)逕

節逕(jing)

齒根逕

外逕

節(jie)逕(jing)

齒(chi)根(gen)逕(jing)

10

93

82.2

66.32

114

102.8

83.7

140

123.3

101.07

187

164.4

135.8

11

102

90.16

73.36

127

112.7

92.5

153

135

111.63

204

180.3

150

12

110

98.14

82.26

138

122.7

103.62

165

147.2

124.98

220

196.3

167.4

13

118

106.1

89.48

148

132.7

112.65

177

159.2

135.81

237

212.3

182.1

14

127

114.2

98.27

158

142.7

123.63

190

171.2

149

253

228.3

199.7

15

135

122.2

105.62

168

152.7

132.82

202

183.3

160

269

244.3

214.4

16

143

130.2

114.32

179

162.7

143.69

214

195.3

173.1

286

260.4

231.8

18

159

146.3

130.39

199

182.8

163.79

239

220

197.2

319

292.6

264

20

176

162.4

146.49

220

203

183.91

263

243.6

221.3

351

324.2

296.2

24

208

194.6

178.72

260

243.3

224.2

312

291.9

269.7

416

389.2

360.6
